The 214-3339-00-0602J is a 0.1-inch 14-lead green ZIP DIP Socket made of glass-filled polysulfone. It is easily disassembles for repair-ability and has contact point of 0.11-inch below top surface of socket.

• 1A Current rating
• >1 x 10R at 500VDC Insulation resistance
• UL94V-0 Flammability rating
• -55 to 150C Operating temperature range
• 0.3″ Distance between rows

Applications

Industrial

Product details

No. of Contacts: 14Contacts Connector Type: DIP Socket Pitch Spacing: 2.54mm Product Range: Text Tool Row Pitch: 7.62mm Contact Material: Beryllium Copper Contact Plating: Gold Plated Contacts

Other details

Brand 3M Part Number 214-3339-00-0602J Quantity Each Technical Data Sheet EN
